• The DuraBike Lumenux

    broken image

    Lumenux Options & Pricing

    broken image
  • How It Works

    1

    Choose your ebike Class

    • Class I (18 mph)
    • Class III (28mph)
    2

    Choose your Gearbox

    • Pinon 6 or 12 speeds
    • Pinon twist shift or electronic SmartShift
    3

    Choose your color

    The most difficult part is finding your color. Choose your color on prismaticpowders.com

    4

    Contact DuraBike

    Use the contact form to place your order. 50% down at the time of order.

  • Details

    Lumenux Overview

    The Lumenux is the perfect commuter ebike. It's built for long-term reliability, low maintenance, and rider comfort. The ride quality is smooth and intuitive. The nuetral headtube angle and moderate chainstay lengths combine for confident steering and handling at all speeds up to 30 mph. The Lumenux is 100% fun to ride. Carve corners. Tour country roads. Blast past commuter traffic. Street, gravel, or bike paths, the Lumenux gets you there and back without having to worry about running out of battery or bike maintenance.



    The Lumenex is equiped with servicable front suspension, 27.5x2.4" tires, 20mm riser bars, Ergon grips and saddle for comfort. Aside from the premium NeoDrive ebike system, all components are industry standards, which allows any local bike shop to perform routine maintenace or replace components.

    Frame Specs

    Sizes: Small - Medium - Large



    Frame:

    • Heat treated aluminum, optimized geo for 100-120mm suspension fork
    • Direct mount kickstand
    • horizontal sliding dropouts
    • Rack and Fender mounts
    • Frame Split for Belts
    • 1x Waterbottle mount

    Colors: Pick you custom color at PrismaticPowders.com

    Tires: 27.5" x 2.4"

    Head Tube: ZS44 upper / ZS56 lower, fits tapered steer tubes

    Bottom Bracket: No need, it's part of the gearbox

    Spacing: Boost 110mm x 15mm front; 142mm x 12 rear

    Seat Post: 31.6

    Complete Bike Specs

    Frame: DuraBike Lumenux

    E-Motor System: NeoDrives Z20 RS Class I or Class III

    Rear Hub Motor: NeoDrives Z20RS, 500w (1,200w peak), 40 Nm torque

    Battery: BMZ V8, 48v, 13.4Ah, 650Wh

    Fork: Manatou Machette

    Headset: Cane Creek 40

    Gearbox: Pinion C6, C12, C6i Smart Shift, or C12i Smart Shift

    Shifter: Pinion twist shifter or Pinion Smart Shift electric

    Chain ring & Cog: Gates CDX SL

    Front Hub: Velocity boost 110



    Rims: Velocity Cliffhanger

    Brakes: Magura MT Trail hydraulic - 4 piston front, 2 piston rear

    Tires: Schwalbe Supermotor 27.5x2.4"

    Tire Liners: Tanus

    Saddle: Ergon

    Grips: Ergon

    Handlebard: Thomson Elite aluminum 20mm rise x 750mm wide

    Stem: Thomson Elite aluminum 31.8x50mm

    Seatpost: Thomson Elite aluminum 367mm

    Headset Spacers: Thomson

    Seatcollar: Thomson



    Safety & Service Life

    Many ebike companies focus on first time sales, but not on long-term service life. DuraBike is future focused and designs bike to be riden for many years and thousands of miles. DuraBike features NeoDrives ebike systems and BMZ batteries. NeoDrives is a subset of the German company, Alber, formed in 1986. Alber provides mobility devices to the medical industry. NeoDrive ebike motors are 100% manufactured in Germany using the same precision production systems as other Alber products. BMZ Innovation Group is a German company that specializes in lithium-ion battery systems for over 30 years. BMZ's vision is to promote electrification to reduce the global CO2 footprint. All BMZ battery systems are made in German and undergo rigorous quality testing and are CE certified.

  • broken image


    Frame Geometry


    Comfortable - Fun - Confident

  • Learn more about your options

    Which gearbox is right for you?

    broken image

    The Pinion C-Line Gearboxes are light and reliable

    Learn more here: https://pinion.eu/en/c-line

    In our experience 6-speed gearboxes work well for Class-I ebikes and 12-speed gearboxes are needed for Class-III ebikes.

    broken image

    The Pinion SmartShift is a revolutionary electronic shifting gearbox

    Learn more here: https://pinion.eu/en/smartshift



    Both twist-shift and SmartShift systems work well. The SmartShift system shifts quicker and easier than the twist-shift and is our honest preference.

    broken image

    The NeoDrive ebike system is the benchmark of hub motor systems
